124 Rockwell Automation Publication 5000-UM005B-EN-P - November 2015
Appendix A Troubleshoot Your Module
Steady red The module has experienced a non-recoverable fault. Replace the module.
Flashing red One of the following conditions exist:
• A module firmware update is in progress.
• A module firmware update attempt failed.
• The device has experienced a recoverable fault.
• A connection to the module has timed out.
Complete one of the following:
• Let the firmware update progress complete.
• Re-attempt a firmware update after one fails.
• Use the Logix Designer application to determine the cause of the
module fault.
The Connection and Module Info categories of the module’s
configuration indicate the fault type.
To clear a recoverable fault, complete one of the following:
– Cycle module power.
– Click Reset Module in the Logix Designer project via the Module Info
category of the Module Properties dialog box.
If the fault does not clear after cycling power and clicking Reset Module,
contact Rockwell Automation Technical Support.
• Use the Logix Designer application to determine if a connection has
timed out. The Connection category in the Module Properties for the
module indicates the module state, including if a connection has
timed out.
If a connection has timed out, determine the cause and correct it. For
example, a cable failure can cause a connection timeout.
The following
sequence:
1. Steady red for
approximately 2
seconds
2. Flashing green
indefinitely
Module is powering up. Wait for the power-up sequence to finish.
Table 27 - Module (MOD) Status Indicator - 5069 Compact I/O Analog I/O Modules
Indicator State Description Recommended Action
