Appendix B
Module Tag Definitions
Module tags are created when you add a module to the Logix Designer
application project.
The following types of tags are available with the 5069 Compact I/O™ analog I/
O modules:
• Configuration
• Input
• Output
The set of module tags associated with a module depends on the module type
and Module Definition choices made during module configuration. For example,
if you use a Listen Only Connection in the Module Definition, the Logix
Designer application creates only Input tags for that module.
The tables contained in this section list all of the tags available with a module.
Not all tags in the list are used when that module type is added to a project. Tag
use varies by module configuration.
Topic Page
Tag Name Conventions 134
Access the Tags 134
5069-IF8 Module Tags 135
5069-IY4 Module Tags 142
5069-OF4, 5069-OF8 Module Tags 153
