Configure the Module Chapter 6
Chxx Category
The Chxx category, where xx represents the channel number, shows the
configuration options available for the channel. The Scaling and Filter options
correspond to the input type and range for the channel.
If desired, you can disable the channel on this dialog box.
Alarms Category
Each channel on the 5069-IF8 module has an Alarms category with which it is
associated. The Signal Units correspond to the input type and range for
the channel.
If desired, you can disable alarms on this dialog box.
