152 Rockwell Automation Publication 2099-UM001D-EN-P - December 2012
Appendix A Specifications and Dimensions
Table 60 - Bussmann Fuse Recommendations
Contactor Ratings
The table below lists the recommended contactor ratings for Kinetix 7000 drives
installed without a Line Interface Module (LIM).
Power Dissipation
Specifications
Use this table to size an enclosure and calculate required ventilation for your
Kinetix 7000 drive system.
Drive Cat. No.
Drive Current
Rating (Adc)
Recommended
Fuse
Fuse Current
Rating
i²t (A²Sec)
Peak Let-Through Current
at 100kA rmsPre-Arc
Max Clearing @
600V AC
2099-BM06-S 42.9 FWJ-80A 80 1550 9700 6300 A
2099-BM07-S 55.7 FWJ-100A 100 2800 17500 8000 A
2099-BM08-S 69.7 FWJ-125A 125 4800 35000 10000 A
2099-BM09-S 105 FWJ-175A 175 7500 65000 12000 A
2099-BM10-S 137 FWJ-200A 200 11700 80000 13000 A
2099-BM11-S 204 FWJ-500A 500 39500 329000 21000 A
2099-BM12-S 281 FWJ-500A 500 39500 329000 21000 A
Drive Cat. No. Contactor Safety Contactor Coil Type Coil Voltage Requirements
2099-BM06-S 100-C43DJ01 100S-C43-DJD4C Standard with Diode 24V DC
2099-BM07-S
100-D95EN11 100S-D95EN22C
Electronic Coil
(1)
24V DC for control and 480V AC for coil power
2099-BM08-S
2099-BM09-S
2099-BM10-S 100-D140EN11 100S-D140EN22C
2099-BM11-S 100-D180EN11 100S-D180EN22C
2099-BM12-S 100-D250EN11 100S-D250EN22C
(1) Electronic coil control power requirements = 24V DC @ 15 mA.
Drive Cat. No.
Usage as a % of Rated Power Output
W
50% 100%
2099-BM06-S 294 465
2099-BM07-S 388 619
2099-BM08-S 452 730
2099-BM09-S 645 1072
2099-BM10-S 882 1479
2099-BM11-S 1275 2125
2099-BM12-S 1438 2437
