Connect the Kinetix 7000 Drive System Chapter 4
Power Wire Specifications
Wire should be copper with 75 °C (167 °F) minimum rating. Phasing of main
AC power is arbitrary and earth ground connection is required for safe and
proper operation.
For additional information see Power Specifications on page 150
, and
Interconnect Diagram Notes on page 162
for interconnect diagrams.
ATTENTION: This drive contains ESD (Electrostatic Discharge) sensitive parts
and assemblies. You are required to follow static control precautions when you
install, test, service, or repair this assembly. If you do not follow ESD control
procedures, components can be damaged. If you are not familiar with static
control procedures.
See publication 8000-4.5.2
, Guarding Against Electrostatic Damage or any other
applicable ESD protection handbook.
ATTENTION: To avoid personal injury and/or equipment damage, be sure the
installation complies with specifications regarding wire types, conductor sizes,
branch circuit protection, and disconnect devices. The National Electrical Code
(NEC) and local codes outline provisions for safely installing electrical
equipment
To avoid personal injury and/or equipment damage, be sure the motor power
connectors are used for connection purposes only. Do not use them to turn the unit
on and off.
To avoid personal injury and/or equipment damage, be sure the shielded power
cables are grounded to prevent potentially high voltages on the shield.
