Chapter 1 Start
The Kinetix 7000 drive system shown in Figure 4 below illustrates a DC
common bus configuration with two follower Kinetix 7000 (2099-BM11-S)
drives and an 8720MC regenerative power supply (RPS). In full-line regenerative
mode the 8720MC-RPS190 unit provides motoring and regenerative power.
Figure 4 - Kinetix 7000 System Configuration with AC Input and 8720MC-RPS190 with Full-line
Regeneration
1606-XL
Power Supply
Input
Allen-Bradley
R
EGE
NER
ATIVE PO
WER SUPPLY
REGENERATIVE PO
WER SUPPLY
87208720
MCMC
RST
PRG
ENT
READYREADY
FAULTFAULT
PROGRAMPROGRAM kWkW
V
A
1606-XL
Power Supply
Input
Allen-Bradley
R
EGENE
RA
TIVE
POW
ER
SU
PPLY
87208720
MCMC
RST
PRG
ENT
READYREADY
FAULFAULT
PR
OGRAMPROGRAM kWkW
V
A
2090-SCxxx-x
SERCOS Fiber-optic Ring
DC Bus
Kinetix 7000 Drive
2099-BM11-S
2090-K6CK-Dxxx
Low Profile Connector
Kits for I/O, Motor and
Auxiliary Feedback
8720MC-RPS190BM
Regenerative Power Supply
Three-phase
Input Power
8720MC-EF190-VB
EMC Line Filter
This unit includes an AC line filter (required for CE), magnetic
contactor, harmonic filter, and varistor.
IMPORTANT The 8720MC-EF190-VB line filter unit and two
8720MC-LR10-100B line reactors are required when using the
8720MC-RPS190 regenerative power supply.
Input
Fusing
Full Regenerative
2099-BM11-S
Kinetix 7000 Drive
2090-K6CK-Dxxx
Low Profile Connector
Kits for I/O, Motor and
Auxiliary Feedback
1606-XLxxx
24V DC
Control Power
1606-XLxxx
24V DC
Control Power
Encoder
Feedback Cable
Motor
Power Cable
HPK-Series Motors
DC Bus
Fusing
DC Bus
Fusing
Control Power
Supply Input
Control Power
Supply Input
Logix SERCOS
interface Module
RSLogix 5000 Software
Logix Controller
Programming Network
8720MC-LR10-100B
Line Reactor
(two units in parallel)
Encoder
Feedback
Cable
Motor
Power Cable
HPK-Series Motors, RDD-Series Direct
Drive Motors, MPM-B165xx and MPM-
B215xx, and MPL-B5xxx, MPL-B6xxx,
MPL-B8xxx, and MPL-B9xxx (shown)
Servo Motors
Ground
Fault
Protection
Fusing
