Allen-Bradley Kinetix 7000 User Manual

Rockwell Automation Publication 2099-UM001D-EN-P - December 2012 97
Connect the Kinetix 7000 Drive System Chapter 4
Figure 55 - Panel-mounted Breakout Board Connection Example
2090-UXBC-D15xx
Breakout Cable
See the Motor Feedback Breakout Board
Installation Instructions, publication 2090-IN006
,
for Connector Breakout Board Specifications.
Kinetix 7000 Drive
(Side View)
2090-UXBB-D15xx
Panel-mounted Breakout Board
