Rockwell Automation Publication 1756-PM006I-EN-P - February 2018 59
Chapter 2
Program a sequential function chart
To add SFC elements, use the SFC toolbar.
1. On the SFC toolbar, click the button for the item that you want to add.
2. Drag the element to the required location on the SFC.
3. To wire (connect) two elements together, click a pin on one of the elements
and then click the pin on the other element . A green dot shows a
valid connection point.
Introduction
Add and manually connect
elements
