152 Rockwell Automation Publication 2711P-UM006A-EN-P - November 2010
Chapter 9 Troubleshoot the System
2. Press the up and down arrow keys on the keypad or attached keyboard to
move up and down the list or maintenance options:
• Continue booting with selection option.
• Special Boot Action
• Display Resolution
3. With an option selected, press the right or left arrow keys to cycle through
the available operations or settings.
The result of each action is explained on the right.
4. Follow these steps, when done making selections:
a. Press the up arrow to return to ‘Select Continue booting with selected
options’.
b. Press the Enter key to continue booting.
Maintenance Window with Safe Mode Selected
default button pressed, please select maintenance options
Maintenance Menu -- ver 01.01
Special BOOT Action - SAFE Mode
Display resolution - AUTO
Continue booting with selected options
Selects the special BOOT action
that will be executed during this
system boot.
- SAFE mode-------------------------
The system will start in the
Configuration Mode of FactoryTalk
View ME Station.
- IMPORTANT-------------------------
FactoryTalk View ME Station will
load at start up not the customer
HMI application. The HMI
application will start normally the
next time the terminal is
rebooted.
The version refers to
the boot loader.
