Allen-Bradley POINT I/O User Manual

Publication 1734-UM014A-EN-P - November 2010
Configure the Adapter for Direct Connection and Rack Optimization in RSLogix 5000 Software 67
• For RSLogix 5000 programming instructions, refer to Getting Results
with RSLogix 5000, publication LG5000-GR001
.
• For ControlLogix controller information, refer to ControlLogix System
User Manual, publication 1756-UM001
.
• Slot Status Bits: The Slot Status bits display the connection status for
each of the POINT I/O modules that use a rack-optimized connection.
– Bit 0 is reserved for the adapter and always reports a value of 1.
– Each of the other bits (1 to 63) correspond to a POINT I/O module
that you install in the POINT I/O backplane.
– In this example, we configured the 1734-AENTR adapter for both
rack-optimized and direct connections.
The slot status bits indicate that we installed the module in slot 2 with
it operating correctly:
0 = module participating with no errors and
1 = module not participating or connection error (typically, module
removed/missing)
