Rockwell Automation Publication 6000-IN100A-EN-P - August 2020 51
Chapter 3 Drive Electrical Interconnection
A typical connection with connection points on the left side of the power
module cabinet are shown in the following diagrams (Figure 29
, Figure 30).
Figure 29 - 4.16 kV Power Module Configuration – A-Frame
U Phase
V Phase
W Phase
Motor cable
to Junction
cabinet
M6x16 bolt
VSB cable
Front View
