Duct Station 120 Series 170/200 Series
A 10 in. [254 mm] 12 in. [305 mm]
B 15 in. [381 mm] 17 in. [432 mm]
C 18 in. [457 mm] 21 in. [533 mm]
D 21 in. [533 mm] 24 in. [610 mm]
E 24 in. [610 mm] 27 in. [686 mm]
F 26 in. [660 mm] 30 in. [762 mm]
G 28 in. [711 mm] 32 in. [813 mm]
H 30 in. [762 mm] 34 in. [864 mm]
I 32 in. [813 mm] 36 in. [914 mm]
J 33 in. [838 mm] 38 in. [965 mm]
K 35 in. [889 mm] 40 in. [1,016 mm]
L 36 in. [914 mm] 42 in. [1,067 mm]
Table 4
NOTE: Table 4 represents units with the same vent size.
If multiple vent sizes are used, consult a local HVAC
specialist.
NOTE: Duct clean-out recommended every 6 feet [183
cm].
Exhaust Requirements
©
