Alliance Laundry Systems CA170L - Page 41

Two Manifold Assemblies
TMB2018N_SVG
1
2
L L
K K
J J
I
AA
I
1. Outlet duct diameter = combined largest duct diameter of both sides
2. 45° typical
Figure 14
Refer to Table 4 for measurements for each manifold.
Exhaust Requirements
©
Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
41 Part No. 70458101ENR10
