14 Rapier Series Switch
C613-03020-00 REV K
Figure 14: Front panel of the Rapier 48i.
Rapier 48w
(Figure 15, Figure 16)
■ 48-port 10BASE-T/100BASE-TX (RJ-45 connectors)
■ Two 1000BASE SFP ports
■ Two asynchronous serial console ports with DB9 connectors
■ One Network Service Module bay, with support for various WAN interface
cards
■ Auto-negotiating Layer 3 Managed Switch
■ Enhanced switching core
■ Replaceable air filters and fan-only modules (FOMs) for NEBS applications
Figure 15: Front panel of the Rapier 48w
Figure 16: Rear panel of the Rapier 48w
