4 Rapier Series Switch
C613-03020-00 REV K
Models Covered by this Document
This Hardware Reference includes information on the following models:
■ Rapier G6 6-port 100BASE-TX/1000BASE-T (RJ-45 connectors)
■ Rapier G6F-LX/SC 6-port 1000BASE-LX (SC fibre connectors)
■ Rapier G6F-SX/SC 6-port 1000BASE-SX (SC fibre connectors)
■ Rapier G6F-SX/MT-RJ 6-port 1000BASE-SX (MT-RJ fibre connectors)
■ Rapier 8/8MT 8-port 10BASE-T/100BASE-TX (RJ-45 connectors)
plus 8-port 100BASE-FX (MT-RJ fibre connectors)
■ Rapier 8/8SC 8-port 10BASE-T/100BASE-TX (RJ-45 connectors)
plus 8-port 100BASE-FX (SC fibre connectors)
■ Rapier 16F-FX/MT-RJ 16-port 100BASE-FX (MT-RJ fibre connectors)
■ Rapier 16Fi-FX/MT-RJ 16-port 100BASE-FX (MT-RJ fibre connectors)
■ Rapier 16F-FX/SC 16-port 100BASE-FX (SC fibre connectors)
■ Rapier 16Fi-FX/SC 16-port 100BASE-FX (SC fibre connectors)
■ Rapier 24 24-port 10BASE-T/100BASE-TX (RJ-45 connectors)
■ Rapier 24i 24-port 10BASE-T/100BASE-TX (RJ-45 connectors)
■ Rapier 48 48-port 10BASE-T/100BASE-TX (RJ-45 connectors)
■ Rapier 48i 48-port 10BASE-T/100BASE-TX (RJ-45 connectors)
■ Rapier 48w 48-port 10BASE-T/100BASE-TX (RJ-45 connectors), 1 NSM bay
You can download updates to this Hardware Reference from
www.alliedtelesis.com/support/software.
Why You Should Read this Document
Use this document to familiarise yourself with Rapier switches and their
hardware features. This reference can also help you with installation and
maintenance. However, refer to the Software Reference for information about
software configuration and installation procedures.
This document also introduces uplink modules, Network Service Modules
(NSM), and Port Interface Card (PIC) expansion options. See “For More
Information” on page 64 for where to find details about these options.
Keep this document or its CD in a safe place; it will be helpful if you purchase
expansion options for the switch.
