Hardware Reference 5
C613-03020-00 REV K
Hardware Overview
This section provides an overview of the hardware features of Rapier Series
Switches. Hardware descriptions for Uplink Modules, NSMs, and PICs can be
found in their respective hardware references. These references can be found
on the CD-ROM bundled with your switch, or can be downloaded from
www.alliedtelesis.com/support/software.
Rapier switches combine wire-speed Layer 2 and 3 switching with full
multiprotocol routing capabilities to deliver low-latency high-bandwidth
traffic capabilities to the desktop. Ethernet, fast Ethernet and gigabit Ethernet
connectivity with both copper and fibre optic interfaces make the Rapier Series
a versatile and powerful switching solution.
Dimensions All models except Rapier 48w
■ Height: 66 mm, plus 5.5 mm if the rubber feet are used
■ Width: 440 mm, excluding rack-mounting brackets
■ Depth: 360 mm
■ Weight: Not more than 7 kg, depending on model and excluding NSMs,
PICs, and power cord
Rapier 48w
■ Height: 110 mm
■ Width: 440 mm, excluding rack-mounting brackets
■ Depth: 230 mm
■ Weight: Not more than 8 kg, excluding NSMs, PICs, and power cord
Mounting System All models except Rapier 48w
■ 1.5U rack mounting
Rapier 48w
■ 2.5U rack mounting
Environmental
Conditions
All models except Rapier 48w
■ Operating temperature range: 0 to 40º C (32 to 104º F)
■ Storage temperature range: -25 to 70º C (-13 to 158º F)
■ Relative humidity range: 5 to 95% non-condensing
Rapier 48w
■ Operating temperature range: 0 to 50º C (32 to 122º F)
■ Storage temperature range: -25 to 70º C (-13 to 158º F)
■ Operating relative humidity range: 5 to 95% non-condensing
■ Operating altitude: maximum 3,050 metres (10,000 feet)
