32 Rapier Series Switch
C613-03020-00 REV K
Rapier Switches and their expansion options support a wide range of interface
types, including Ethernet, asynchronous, synchronous, Basic Rate ISDN and
Primary Rate ISDN. Each interface type (except Ethernet interfaces on the AT-
AR026) can be tested independently using the Test Facility software. The
following examples show how to test specific interfaces.
Test results are displayed with the command:
SHOW TEST
This produces a display similar that shown in Figure 23.
Figure 23: Example output from the show test command
10/100 Ethernet LAN Port Tests
A loopback plug is required to run the first part of the Ethernet LAN test. See
“Loopback Plugs for Testing Switch Interfaces” on page 31 for details of how to
make a loopback plug. To start an Ethernet interface test, use the command:
ENABLE TEST INT=PORTn
where n is the Ethernet interface number. The test will run for 4 minutes. Use
the show test command to observe the test progress.
Board ID Bay Board Name Rev Serial number
----------------------------------------------------------------------------
Base 108 AT-RP24 Rapier 24 M1-1 6845425
Uplink 88 1 AT-A35SX/SC-00 P1-0 14269019
Duration Details
Interface State Result Type (minutes) Data( %OK ) Control
----------------------------------------------------------------------------
port1 no test - - - - - -
port2 no test - - - - - -
port3 no test - - - - - -
port4 no test - - - - - -
port5 no test - - - - - -
port6 no test - - - - - -
port7 no test - - - - - -
port8 no test - - - - - -
port9 no test - - - - - -
port10 no test - - - - - -
port11 no test - - - - - -
port12 no test - - - - - -
port13 no test - - - - - -
port14 no test - - - - - -
port15 no test - - - - - -
port16 no test - - - - - -
port17 no test - - - - - -
port18 no test - - - - - -
port19 no test - - - - - -
port20 no test - - - - - -
port21 no test - - - - - -
port22 no test - - - - - -
port23 no test - - - - - -
port24 no test - - - - - -
port26 no test - - - - - -
asyn0 no test - - - - - -
----------------------------------------------------------------------------
