Hardware Reference 35
C613-03020-00 REV K
Table 12: System LEDs on the Rapier 48w
LED State Function
Power Green The switch is receiving power and the
voltage is within the acceptable range.
Fault Red The switch or management software is
malfunctioning.
1 flash A switch fan has failed.
In use
(front panel)
Green An NSM is installed, is receiving power, and
is operational. The NSM and its PICs are not
ready to be hot swapped.
Off No NSM is installed, or the switch has not
recognised the NSM.
Swap
(front panel)
Green The NSM and its PICs are ready to be hot
swapped.
Off The Hot Swap button must be pressed
before the NSM or PICs can be hot swapped,
or the software version does not support hot
swapping
1
.
1. Hot swapping is supported by Software Version 2.3.1 or later. AT-AR021(S) BRI S/T, AT-AR021(U)
BRI U, and AT-AR023 SYN PICs can be hot swapped.
Table 13: Switch Port LEDs on the Rapier G6
LED State Function
L/A
(Link/Activity)
Green A 1000 Mbps link is open
Amber A 10 Mbps or 100 Mbps link is open
Flashing Green 1000 Mbps activity is occurring
Flashing Amber 10 Mbps or 100 Mbps activity is occurring
D/C
(Duplex/Collision)
Green The port is operating at full-duplex
Amber The port is operating at half-duplex
Flashing Amber Collisions are occurring on the line
Table 14: Switch Port LEDs on the Rapier G6F-LX/SC, G6F-SX/SC, and G6F-SX/MT-RJ
LED State Function
L/A
(Link/Activity)
Green A 1000 Mbps link is open
Flashing Green 1000 Mbps activity is occurring
D/C
(Duplex/Collision)
Green The port is operating at full-duplex
Amber The port is operating at half-duplex
Flashing Amber Collisions are occurring on the line
