No. Display Description Remedy
791 Lost ModBus
communication
SEC board no longer reachable for some time.
791 is triggered if an HeatingIO board has been found
(without separate coding), but no SEC board can be
detected on it
If it concerns the SEC configuration,
test the ModBus cable between the
HeatingIO and SEC board. Also check the
SEC board to see whether everything is
flashing as it should
If it is NOT a configuration with SEC
board (e.g., because it concerns a P184
unit), check the coding resistor of the
HeatingIO
792
LIN-connection lost Unable to find a master board or any configuration Check the coding connector on the LIN
board(s)
793
Major VSS fault Temperature sensor fault in the inverter Fault acknowledges itself
794 Overvoltage Overvoltage on inverter Inspect the inverter voltage supply
795 Undervoltage Undervoltage on inverter Inspect the inverter voltage supply
796
Safety switch o
„Safety input was triggered
Case 1 - Inverter malfunction
Reset automatically?
Case 2 - High-pressure pressostats in refrigerating circuit have
triggered
Reset automatically?”
„Case 1 - Inspect inverter.
Remedy fault
Case 2 - Inspect HW throughow, overow,
ow temperature sensor and high-
pressure sensor.
Remedy fault.”
797 MLRH is not supported Heating rod regulating is not supported -
798 ModBus connection lost "ModBus error on fan. Reset automatically.” Inspect ModBus cabling to fan
799
ModBus connection lost
"ModBus error on ASB electronic printed circuit board. Reset
automatically.“
Inspect ModBus cabling to ASB electronic
printed circuit board
ACKNOWLEDGING A FAULT
If a fault occurs and an error message appears in the screen, then:
Notice error number.
Acknowledge error message by pressing the “rotary pushbutton“ (for 7 seconds).
The screen changes from the error message to the navigation screen.
If this error message occurs again, contact the tter or authorised service personnel (= customer service),
if the error message prompted you to do this. Communicate error number and arrange further procedure..
FLASHING CODES ON CONTROLLER BOARD
Green LED ashes every second everything ok
Red LED ashes briey for short Data being received over LIN bus
Green and red LED light up The board can receive a software update
During the software update the green LED is lit and the red one ickers quickly
