Parameter Factory setting Setting Start-up Value range Access
Error No No • Heating • Domestic Water • Yes*) No • Heating • Domestic Water • Yes Fitter
Service water 1 Sensor Sensor • Thermal *) Sensor • Thermal
User
Service water 2 CP CP • h.w.CP *) CP • h.w.CP
Fitter
Service water 3 with CP wo. CP • with CP *) wo. CP • with CP
Fitter
Service water 4 set value. set value • max value *) set value • max value
Plant
Service water 5 device-dependent wo HSP • with HSP *) wo HSP • with HSP
Fitter
SW+HP max 0 h h *) 0 h – 8 h
User
Defr cycle max 45 min min *) 45 • 60 • 90 • 120 • 180 • 240 • 300 min
Fitter
Defrost. Air.. No No • Yes *) No • Yes
AS
Defr. Air max 15 min min *) 5 min – 30 min
AS
Defrost 2 with 1CP with 1CP • with 2CP *) with 1CP • with 2CP
Plant
Pump opt. Yes No • Yes *) Suppl. pump • CP
User
Access Fitter User • Fitter • AS *) User • Fitter • AS
AS
Heat source
only SWP BG 1
No No • Brine • Water, • Water/Brine No • Brine • Water, • Water/Brine AS
Brine pres/Flow device-dependent
No • Flow • Brine pres •
Pow.suppl. • pow.a ow *)
No • Flow • Brine pres •
Pow.suppl. • pow.a ow
AS
Fitter
Control CP On O • On *) O • On
AS
Setting hc set. AT set. AT • Fixed Tp. *) set. AT • Fixed Tp.
Fitter
Setting mc 1 set. AT set. AT • Fixed Tp. *) set. AT • Fixed Tp.
Fitter
Speed MK1 fast fast • medium • slow fast • medium • slow
Fitter
Screed heating w. mixer wo. mixer • w. mixer *) wo. mixer • w. mixer
User
El. Anode device-dependent No • Yes *) No • Yes
AS
Heating limit Yes No • Yes *) No • Yes
User
Parall. operation No No • Slave • Master *) No • Slave • Master
Fitter
Remote
maintenance
No No • Yes *) No • Yes
User
Pump optim. Time 180 min *) 5 – 180 min
User
eciency pump No No • Yes *) No • Yes
Fitter
heat quantity
Fitter
min defrost cycle 45 min min 45 • 60 • 90 • 120 • 180 • 240 • 300
Fitter
TDI Message Yes No • Yes *) No • Yes
Fitter
release 2hg 60 min min 20 min - 120 min
Fitter
aux. heat. hot water No No • Yes *) No • Yes
Fitter
