Chapter I Purchase Inspection
7
Chapter I Purchase Inspection
1.1 Unpacking Inspection
The servo drive system has been tested and checked strictly before delivery. However,
please check the purchased product of the following items to avoid unnecessary
mistakes during purchasing and transport.
 Whether the purchased product is the expected one: for this, the product model on
the nameplates of the motor and drive should be checked with reference to model
description outlined in the next section.
 Whether the motor shaft rotates in a smooth manner: for this, manually rotate the
motor shaft to see whether it is able to run smoothly. If yes, it is deemed normal.
However, the inspection manner of manual rotation is not applicable to the motor
with an electromagnetic holding brake.
 Damage inspection: for this, conduct visual inspection on the product for damage
or scratching.
 Unreliable screws: check whether any screw is not fixed in a reliable manner or is
loosening.
In any of above mentioned cases, do not hesitate to contact the dealer for problem
solving.
Operable complete servo components include:
Name
Qty.
Unit
Remarks
Servo motor
1
Set
Servo drive
1
Set
Motor power line
connector
1
Set
Standard configuration: one 4P
aviation plug, one 4P quick
connector. Optional power cable
Encoder signal line
connector
1
Set
Standard configuration: one 15P
aviation plug, one DB15 RP-SMA
Male
Optional coder signal line
Spring opener
2
Pcs.
Standard configuration: for spring
connector wiring
Instruction Manual
1
Copy
