Alpha CXPS-C - Figure 18 - Distribution Bay-DC Distribution Bus

239400001-J1 Rev F
Figure 18 — Distribution Bay—DC Distribution Bus
4.3.11 DC Distribution Buses
Each distribution bay has a vertical distribution bus (see Figure 18) that brings power from the overhead busbars
down into the bay. This bus is rated for 6000A continuous operation.
LVD contactor
(optional)
Main vertical
busbar
Shunts
