9400001-J1 Rev F
52
8.3.1 Wiring the AC Distribution Panel
WARNING!
Verify that AC breakers are off and locked out at the AC Input Panel.
NOTE:
Wire one side at a time with only one door open. Working with both doors open may
make it difcult to close both doors when the wiring is complete.
Figure 45 — Pre Wired 8-feed AC Panel - 3 Phase, 3 Wire 208/480 Vac
Knockouts
