Alpha CXPS-C - Page 69

SCALE:
REV
SHEET
SIZE
DWG NO.
TITLE:
OF
B
1:12
B
1 4
0250002-06
CENTRALIZED PLANT DIST.
OUTLINE DRAWING
THESE DESIGNS AND SPECIFICATIONS ARE
CONFIDENTIAL, REMAIN THE PROPERTY OF
ALPHA TECHNOLOGIES LTD., AND SHALL NOT BE
COPIED OR USED WITHOUT ITS WRITTEN CONSENT
© ALPHA TECHNOLOGIES LTD
CHECKED DRAWN
DATE
APPROVALS
C. COOMBES
OCT-22-12 OCT-22-12
S. BIENKO
X.X X.XX X.XXX ANGULAR:
THIRD ANGLE PROJECTION
UNLESS OTHERWISE SPECIFIED
DIM ARE IN INCHES
INTERPRET DIM AND TOL PER
ASME Y14.5-1994
0.040
1
0.020
0.010
PRODUCT TO BE FABRICATED ACCORDING TO ATL PRODUCTION STANDARD 0700001
1.
CUSTOMER CONNECTION BUSBAR LOCATION DIMENSIONS ARE FROM THE REAR OUTSIDE EDGE OF THE
2.
ENCLOSURES TO THE FRONT FACES OF THE CUSTOMER CONNECTION BUSBARS AND FROM THE LEFT OUTSIDE EDGE OF THE ENCLOSURE TO THE LEFT EDGES OF THE CUSTOMER CONNECTION BUSBARS
NOTES UNLESS OTHERWISE SPECIFIED:
28.0 TYP 28.0 TYP
84.0 TYP
RECTIFIER BAY
MAXIMUM 3 RECTIFIER BAYS PER SYSTEM
DISTRIBUTION BAY
MAXIMUM 6 DISTRIBUTION BAYS PER SYSTEM
ADDITIONAL DISTRIBUTION BAY
ADDITIONAL RECTIFIER BAY
OUTSIDE EDGES OF ENCLOSURE
FRONT VIEW OF SYSTEM
REVISIONS
LTR
DESCRIPTION
BP
DWN
DATE
CHK
A B C
D
E
123
4
5
D
A C
E
B
13
5
4
2
DO NOT SCALE DRAWING
