Alpha CXPS-C - Page 75

SCALE:
REV
SHEET
SIZE
DWG NO.
TITLE:
OF
C
1:12
B
3 4
0250009-06
CENTRALIZED PLANT RECT.
OUTLINE DRAWING
PRODUCT TO BE FABRICATED ACCORDING TO ATL PRODUCTION STANDARD 0700001
1.
CUSTOMER CONNECTION BUSBAR LOCATION DIMENSIONS ARE FROM THE REAR OUTSIDE EDGE OF THE
2.
ENCLOSURES TO THE FRONT FACES OF THE CUSTOMER CONNECTION BUSBARS AND FROM THE LEFT OUTSIDE EDGE OF THE ENCLOSURE TO THE LEFT EDGES OF THE CUSTOMER CONNECTION BUSBARS
NOTES UNLESS OTHERWISE SPECIFIED:
28.00 TYP
84.00
TYP
4.40
15.00
5
28.00 TYP
15.00
15.13
7.00
DISTRIBUTION BAY
MAXIMUM 6 DISTRIBUTION BAYS PER SYSTEM
ADDITIONAL DISTRIBUTION BAY
RECTIFIER BAYRECTIFIER BAYRECTIFIER BAY
OUTSIDE EDGES OF ENCLOSURE
FRONT VIEW OF SYSTEM 10000A BUSWORK SHOWN
DO NOT SCALE DRAWING
2
4
5
3 1
B
E
C A
D
5
4
3 2 1
E
D
C
B A
