Altera Corporation 15
Nios Development Board Reference Manual, Cyclone Edition Board Components
Table 5 below provides compact flash pin out details
Table 5. Compact Flash (CON3) Pin Table (Part 1 of 2)
Cyclone Device
Pin (U60)
Compact Flash Pin
(CON3)
Compact Flash Function
GND 1 GND
F18 2 D03
E17 3 D04
D17 4 D05
D18 5 D06
C18 6 D07
H20 7 -CE
J15 8 A10
D13 9 -OE
J20 10 A09
H14 11 A08
J14 12 A07
VCC 13 VCC
J17 14 A06
J18 15 A05
K15 16 A04
W18 17 A03
H19 18 A02
H18 19 A01
H17 20 A00
F20 21 D00
F15 22 D01
E19 23 D02
H16 24 WP
GND 25 -CD2
B13 26 -CD1
F17 27 D11
E18 28 D12
F16 29 D13
F19 30 D14
G16 31 D15
U19 32 -CE2
GND 33 -VS1
G19 34 -OIORD
