-10-
8.11 MENU - The MENU key allows the user to enter the edit menu. The global timers, input class
output assignment, output configuration and the time and date may be viewed and adjusted
using the MENU key.
8.12 UNITS/TENS - 8UNITS/9UNITS keys increase or decrease values by one. The 6TENS/7TENS
keys increase or decrease values by ten. These keys are used to increase or decrease channel
numbers, timers and to move the pointer in the menu screen.
8.13 F1 - Function key F1 displays the hourmeter and servicemeter messages.
8.14 F2 - Function key F2 displays the time and date of the first fault.
8.15 F1 and F2 keys can be used in conjunction with other keys to implement custom functions.
9.0 UNDERSTANDING THE HOME SCREENS
9.1 The "home screens" are described as a series of screens used to display several of the most
critical operating parameters on one screen. All of the home screens provide a status word on
the upper line, and typically the engine speed on the second line, the suction pressure on the
third line and the discharge pressure on the fourth line. Other analog parameters may be
programmed in for the second, third and fourth lines.
The status line will read one of the following: TIMERS ACTIVE, RUNNING,
TEST XXX SEC, FAULT AL12, MANUAL STOP, AUTO START.
The LCD display always reverts back to one of the home screens after a keypad operation is
completed or the operation times out.
9.2 To manually start the engine, press the RESET button. The “TIMERS ACTIVE” message will
be displayed and remains until all Class B and Class C inputs have been armed. During the
time that the Class B and Class C timers are still active, manually purge and crank the engine.
STATUS TIMERS ACTIVE
SPEED 330 RPM
SUCTION 102.3 PSIA
DISCHARGE 200 PSIG
