-31-

14.10 To edit the output configuration, choose “EDIT SAFETY SHUTDOWN” from the main menu.

Select “MORE MENUS” from the following menu. Finally, select “OUTPUT CONFIG.” from

the last menu.

EDIT SETPOINTS

VIEW INPUT CLASS

EDIT GLOBAL VALUES

6MORE MENUS

6OUTPUT CONFIG.

EDIT TIME AND DATE

COMMUNICATIONS

TO PREVIOUS MENU

OUTPUT6 1 2

DELAY TIME 0 SEC

N/O N/C IGN

A selection arrow pointing to output 1 along with output 1’s delay time and a diamond showing

whether it is configured for N/O (normally open), N/C (normally closed), or IGN (ignition

output module 691124) will be shown. To view an output’s configuration, use the NEXT or

TENS or TENS keys to place the selection arrow in front of the output to be viewed. The

output’s time delay and output state will be shown for each output.

OUTPUT1 2

DELAY TIME 0 SEC

N/O N/C IGN
