14.7 To view or edit safety shutdown values, choose “EDIT SAFETY SHUTDOWN” from the main

menu. To edit or view setpoints choose “EDIT SETPOINTS”.

ENTER

press to

enter the

screens

EDIT CONTROL VALUES

6EDIT SAFETY SHUTDOWN

HOURMETER FUNCTIONS

VIEW FIRMWARE REV.

first group of menu

screens are shown

6EDIT SETPOINTS

VIEW INPUT CLASS

EDIT GLOBAL VALUES

MORE MENUS

CHAN 630

LO SP 20.0 PSIA

HI SP 60.0 PSIA

MANIFOLD PRESSURE

14.8 To view input class, choose “EDIT SAFETY SHUTDOWN” from main menu. Select ‘VIEW

INPUT CLASS” from next menu.

EDIT SETPOINTS

6VIEW INPUT CLASS

EDIT GLOBAL VALUES

MORE MENUS

CHAN 610

INPUT CLASS A B C

300 SECONDS TIME

DELAY ON START-UP

Note: On DE-2500 units which are programmed using Terminal Software Version 2.0 and

above the Sensor Class may be adjusted from the keypad. The “VIEW INPUT CLASS”

display line is replaced by “EDIT INPUT CLASS”. Press NEXT key to access the Class from

screen above and use RIGHT/LEFT ARROW keys to select Class A, B, C. Press ENTER

to save the selection.
