Altronic DE-2500 - Shutdown and Fault Status Screens; First Fault Detection and Acknowledgment

-23-
11.1 (continued)

TENS
press

TENS
then
press
UNITS

then
press
STATUS RUNNING
ARMED
CHAN 40 83 PSIG
COMP OIL PRESSURE
to see channel
41 from channel
40

UNITS
press
STATUS RUNNING
ARMED
CHAN 41 10.5 PSIA
SUCTION PRESSURE
to exit view
channels mode
ESC
press
12.0 SHUTDOWN OR FAULT STATUS SCREENS
12.1 With the engine running and the controller system monitoring points, if a fault occurs, the
display will show the first fault detected. The phrase “1ST FAULT” and “AL12" will be
displayed; “AL1" is for the first output, “AL12" is for outputs one and two. The output or
outputs configured for that channel will trip. The first fault will stay displayed on the screen
until it is acknowledged by one of the keypad keys RESET or ESC. Use VIEW CHAN key to
view the status of all channels.
After all of the current faulted channels are displayed, the display will revert back to the first
fault. If no class A sensors are faulted, pressing the RESET key will clear all displayed faults
and return the display to the timers active home screen. All class B and C input timers and
the output timers will be reset. Pressing the ESC key when the fault screen is displayed will
return the display to the fault home screen. To again view the “first fault” from the fault home
screen, press the VIEW CHAN key.
STATUS FAULT AL12
1st FAULT
CHAN 24
HIGH LIQUID LEVEL 1
Upon a fault,
the first fault is shown.
