9.3 If the AUTO START option is selected when programming the system from the PC, the display
below will appear when the AUTO START sequence begins. The auto start sequence allows
for activation of an electrically controlled pre-lube pump for a programmed time period prior
to cranking. It is recommended that a warning horn or flashing light be activated by the pre-lube
output to inform any personnel which may be present that a cranking attempt is about to begin.
After this user programmed time delay, cranking will begin. A user programmable crank
disconnect speed switch function will automatically disable the starter at the selected RPM. If
the crank disconnect RPM is not reached within a user programmed time period an
OVERCRANK FAULT will be generated turning off the fuel and ignition and disabling the starter
until a new AUTO START command is received.
STATUS AUTO START
SPEED 130 RPM
SUCTION 102.3 PSIA
DISCHARGE 200 PSIG
9.4 After all Class B and Class C points have timed out and are being monitored, and if no faults
are detected, the home screen will show the “RUNNING” message. This is the screen that will
remain under normal operation.
STATUS RUNNING
SPEED 1000 RPM
SUCTION 102.3 PSIA
DISCHARGE 300 PSIG
To Next Page
