-20-
10.0 VIEW PROCESS INFORMATION SCREENS
10.1 The process information screens can be accessed from any of the home screens (except the
test home screen) or from the view channel screen by pressing the VIEW key. There are four
process screens: screens one and three each display up to four user programmed process
variables; screens two and four display an analog bargraph associated with the previous
process variable screen. Thus, up to eight process variables can be displayed both digitally
and in bargraph format.
The analog values are monitored by a microprocessor on the terminal board and are
configured by using a PC and the terminal program . The bargraph end points are set by the
low and high setpoints of the safety shutdown function. Unused channel screens will not be
displayed.
STATUS RUNNING
SPEED 1000 RPM
SUCTION 102.3 PSIA
DISCHARGE 200 PSIG
from
VIEW
press
NOTE: Screens one and two display in digital and bargraph form the first group of four
selected analog inputs.
SUCTION 22 PSIA
DISCHRG 100 PSIG
FILTR 10 PSIA
BOP 110 PSIG
then at
VIEW
press to
view
bargraph
screen
SUCTION L H
DISCHRG L H
FILTR L H
BOP L H
then at
bargraph
screen
VIEW
press to
view
next
screen
