-25-
13.1 (continued)
TEST
press to
enter test
mode
STATUS TEST 600 SEC
SPEED 1000 RPM
SUCTION 102 PSIA
DISCHARGE 200 PSIG
Test screen is shown with
no faulted points. Test
key was pressed from the
“RUNNING” home
screen.
STATUS TEST 525 SEC
1st FAULT
CHAN 24
LIQUID LEVEL STAGE 1
sensor point 24 is
tested.
TEST
press
to test
another
sensor
13.2 When any of the analog channels 30-47 are tested, a “HIGH” or “LOW” indication will
additionally be displayed indicating whether a high or low setpoint was tested. The display
will show the current analog value for the channel selected.
STATUS TEST 530 SEC
1st FAULT HIGH
CHAN 33 5 PSIA
HIGH FILTER PRESS
A high setpoint was
faulted on an analog
input
13.3 If no sensors are faulted and the TEST key is pressed, the display will return to the test home
screen. The test timer will be reset and speed, suction and discharge values will be
displayed.
TEST
press
test key
STATUS TEST 600 SEC
SPEED 1000 RPM
SUCTION 102.3 PSIA
DISCHARGE 200 PSIG
No sensors faulted. Test
home screen is displayed.
