-28-

14.5 To edit the setpoint values, point to “EDIT CONTROL VALUES” and press the ENTER key.

The edit control values menu is shown. The arrow points to the “EDIT SETPOINTS”.

ENTER

press to

edit set-

points

6EDIT SETPOINTS

EDIT PRIM. CONTROLS

CHAN ÷30

LO SP 20.0 PSIA

HI SP 60.0 PSIA

MANIFOLD PRESSURE

14.6 To edit Primary Controls select “EDIT CONTROL VALUES” from main menu and press the

ENTER key. The edit control values menu is shown. The arrow points to the “EDIT PRIM.

CONTROLS”.

ENTER

press to

edit prim.

controls

EDIT SETPOINTS

÷EDIT PRIM. CONTROLS

CONTROL 6 18.0 PSIA

CYCLE TIME 5 s

PROP. BAND 40 %

DEAD BAND 2.2 PSIA
