14.2 To VIEW the controller configuration from the home screen, press the MENU key. Use the
NEXT key to select the group to be viewed and press ENTER. To EDIT the controller
configuration, the controller system requires a password key sequence.
The password procedure is: Press the MENU key. Then press the F2 key followed by the F1
key. Upon pressing this sequence, changes can be made to the configuration.
14.3 The following keys have the same effect in all of the menu screens. If no key is pressed
within one minute, the menu screen will time out and return to the current home screen.
NEXT: The NEXT key moves the selection arrow to the next selection or value without
making a change to the previous value.
UNITS: The UNITS key moves the selection arrow up one selection or increases the
value by one.
UNITS: The UNITS key moves the selection arrow down one selection or decreases the
value by one.
TENS: The TENS key increases the value by ten.
TENS: The TENS key decreases the value by ten.
ENTER: The ENTER key saves the new value and advances the selection arrow to the next
value to be changed.
ESC: The ESC key returns the display back to the previous level of menu screens and
when pressed again back to the current home screen.
14.4 The menu screens have two levels. The first level lists the headings of the items to be
viewed or edited. Upon selecting one of the headings, the second level is displayed. Press
the MENU key to enter the first level of the menu screens. The arrow points to the first
selection to be viewed or edited. Three keys can be used to navigate the first level of menu
selections, NEXT or UNITS or UNITS keys. The NEXT key will move the arrow down one
selection. The UNITS or UNITS keys will move the selector arrow up or down one
selection. Once the arrow is pointing to the selection group to be edited, press the ENTER
key. The display will advance to the second level to view or allow changes to the values.
NOTE: TO EDIT ANY VALUE, THE PASSWORD COMBINATION MUST BE ENTERED
FROM FIRST LEVEL MENU. PRESS THE F2 KEY FOLLOWED BY THE F1 KEY. UPON
PRESSING THIS SEQUENCE, CHANGES CAN BE MADE TO THE CONFIGURATION.
MENU
press to
enter the
menu
screens
6EDIT CONTROL VALUES
EDIT SAFETY SHUTDOWN
HOURMETER FUNCTIONS
VIEW FIRMWARE REV.
first group of menu
screens are shown
Use the following keys to navigate the menu screen.
NEXT
to move
selection
arrow
down
UNITS
to move
selection
arrow
down
UNITS
to move
selection
arrow up
