MODBUS ADDRESS LIST:
ADDRESS DESCRIPTION OF FUNCTION RANGE
40001 RPM 0 to 9999
40002 Hours 0 to 65535
40003 Reserved 0 at all times
40004 Status, 00=start up, 01=running, 60=stop, xx=fault no. 00 to 60
40005 Output status 1-4=bits 0-3 in order, 0=fault, 1=inactive 0 to 16
40006 Inputs 10-17=bits 0-7, 20-27= bits 8-15, 0=faulted 0 to 65535
40007 Inputs 30-37=bits 0-7, 40-46=bits 8-14, 0=faulted, bit 15=1 32768 to 65535
40008 Reserved 65535 at all times
40009 Chan. 30-46 faults, bit 0=1 Lo setpoint bit 1=1 Hi setpoint 0 to 2
40010 From this register to 40049 reserved for future use 0 to 65535
40050 Optional DSM Chan. 1 analog value -9999 to 9999
40051 Optional DSM Chan. 2 analog value -9999 to 9999
40052 Optional DSM Chan. 3 analog value -9999 to 9999
40053 Optional DSM Chan. 4 analog value -9999 to 9999
40054 Optional DSM Chan. 5 analog value -9999 to 9999
40055 Optional DSM Chan. 6 analog value -9999 to 9999
40056 Optional DSM Chan. 7 analog value -9999 to 9999
40057 Optional DSM Chan. 8 analog value -9999 to 9999
40058 Optional DSM Chan. 9 analog value -9999 to 9999
40059 Optional DSM Chan. 10 analog value -9999 to 9999
40060 Optional DSM Chan. 11 analog value -9999 to 9999
40061 Optional DSM Chan. 12 analog value -9999 to 9999
40062 Optional DSM Chan. 13 analog value -9999 to 9999
40063 Optional DSM Chan. 14 analog value -9999 to 9999
40064 Optional DSM Chan. 15 analog value -9999 to 9999
40065 Optional DSM Chan. 16 analog value -9999 to 9999
40066 Optional DSM Chan. 17 analog value -9999 to 9999
40067 Optional DSM Chan. 18 analog value -9999 to 9999
40068 Optional DSM Chan. 19 analog value -9999 to 9999
40069 Optional DSM Chan. 20 analog value -9999 to 9999
40070 Optional DSM Chan. 21 analog value -9999 to 9999
40071 Optional DSM Chan. 22 analog value -9999 to 9999
40072 Optional DSM Chan. 23 analog value -9999 to 9999
40075 Optional DSM Chan. 1 decimal point position from right 0 to 3
40076 Optional DSM Chan. 2 decimal point position from right 0 to 3
40077 Optional DSM Chan. 3 decimal point position from right 0 to 3
40078 Optional DSM Chan. 4 decimal point position from right 0 to 3
40079 Optional DSM Chan. 5 decimal point position from right 0 to 3
40080 Optional DSM Chan. 6 decimal point position from right 0 to 3
40081 Optional DSM Chan. 7 decimal point position from right 0 to 3
40082 Optional DSM Chan. 8 decimal point position from right 0 to 3
40083 Optional DSM Chan. 9 decimal point position from right 0 to 3
40084 Optional DSM Chan. 10 decimal point position from right 0 to 3
