9.9 On some applications, in addition to all of the standard PID control tuning, it may be desirable
to allow for a small controller deadband in order to promote system stability. To set or edit the
PID deadband value, select this function from the Menu as shown.
EDIT SETPOINTS
EDIT PRIM. CONTROL
÷EDIT PID DEADBAND
ENTER
press to
edit PID
deadband
PID #1
DEADBAND 1.0 PSIG
PID #2
DEADBAND 0.2 PSIG
UNITS
press to
change
value
ENTER
press to
accept or
go to next
value
9.10 The TEST home screen is entered by pressing the TEST key. The TEST mode disarms all
outputs and may only be entered from the RUNNING mode. The test time remaining is shown
on the top line. See section 13.0 TEST MODE SCREENS for more information.
TEST
press
to test
STATUS TEST 600 SEC
SPEED 1000 RPM
SUCTION 102.3 PSIA
DISCHARGE 200 PSIG
To Next Page
