ALZRC DEVIL X360 - 页 32

组装说明 ASSEMBLY SECTION
31
FBL 正反牙拉杆组
FBL Pros And Cons Pull Rod Set
Chapter 51
DX360-N
第50步组装完成
Assembled in Chapter 50
FBL 正反牙拉杆
FBL Pros And Cons Pull Rod
24mm
拉杆头
Ball Link
逆牙方向拧入
Tighten it with invers
thread direction
正螺纹
Plus Thread
约50.4mm
Approx 50.4 mm
A
旋翼头初始距离
Preliminary Head Setup
33mm
43mm
FBL 正反牙拉杆组
FBL Pros And Cons Pull Rod Set
Radius 摇臂组
Radius Arm Assembly
十字盘舵机拉杆
Swashplate Servo Pull Rod
