组装说明 ASSEMBLY SECTION
33
电池板安装
Installation of Battery Mount
Chapter 54
DX360-C
第52步组装完成
Assembled in Chapter 52
第53步组装完成
Assembled in Chapter 53
请检查电池板是否锁定卡位。
Please check whether the battery is locked in place.
飞行前的操作
OPERATIONS BEFORE FLIGHT
● 设置遥控器、无刷电调及无副翼陀螺系统。
● 在未装主旋翼和尾旋翼的状态下，认真检查无副翼陀螺系统的正确设置。
● 检查所有线缆、插口是否安装正确。
● 检查皮带松紧度是否正常。
● 检查马达皮带轮的齿轮比，正确设置转速，为确保安全，我们建议不要超过3600转。
* Set up the RC, ESC and flapless gyro system.
* Check the setup of the flapless gyro system with utmost care under non main blade and tail blade status.
* Check all cables and plugs to ensure it is installed correctly.
* Check the correct tension of the tail belt.
* Verify the motor pulley gear ratio, set up a correct revolving speed, our suggestion is do not more than 3600r/min.
齿轮传动比
Gear Ratios
● 9T 14.55:1:4.69
● 10T 13.10:1:4.69
● 11T 11.90:1:4.69
● 12T 10.91:1:4.69
● 13T 10.07:1:4.69
