Amana AOES3030 Series User Manual

10
AKGD3060 Gas Downdraft Cooktop
Installed Above AOES3030 Wall Oven in a
Standard Kitchen Cabinet
10
1
/8" x 3
3
/8" vent location for 10" by 3
1
/4" vent and junction
box indicated in grey. Installation specified is for a 36"
cabinet height, 23
1
/2" minimum depth.
!
WARNING
To avoid property damage or personal injury,
information in these installations must be followed
exactly.
A—6" minimum
B—2
5
/8" right of center line
C—4
3
/8" between top of countertop and top of duct cutout
D—20
5
/8" cutout depth
E—28
7
/8" cutout width
F—
3
/4" from back of cooktop cutout to center of gas entry
into cooktop
G—4
3
/4" from right side of cooktop cutout to center of gas
entry into cooktop
H—28
1
/2" wall oven cutout width
I—27
1
/4" wall oven cutout height
J—4
1
/2" from top of coutertop to top of wall oven cutout
C
L
—Centerline of cutout
Wall oven and gas cooktop must be installed on separate
electrical circuits. Be certain to avoid interference
between the wall oven power supply and the gas supply
lines.
A
B
C
L
C
L
C
Oven and Cooktop
junction box
installed in
adjacent cabinet
D
E
G
H
I
J
F
Gas entry
into cooktop
