15
AOES3030 Wall Ovens Installed Side-by-
Side
Wall oven junction box location indicated in grey.
!
WARNING
To avoid property damage or personal injury,
information in these installation specifications must be
followed exactly.
A
B
C
D
E
A
B
C
D
F
E
G
Solid, full divider
A—2
1
/2" minimum from bottom of countertop
B— 14
1
/8" maximum from center of cutout
C— 24" minimum
D— 28
1
/2 " wall oven cutout width
E— 27
1
/4" wall oven cutout height
F— 1
3
/4" minimum
G—
7
/8" minimum from bottom of countertop to top of
cutout
