Operation of the machine
30
AMASPRAY+ BAG0017.7 10.17
6.1.3 External j (ASD)
An external job can be given to the AMASPRAY
+
via a PDA computer.
This job is always given the job designation AE.
The data is transferred via the serial interface.
• For this purpose, set the transfer rate of the
serial interface to 19200 or 57600 Baud
(Parameter 9).
• For this purpose, the Y-cable is necessary.
Fig. 12/...
(1) Connection for PDA computer
(2) Connection of signal socket or sensor for
impulses per minute (for UF01).
(3) Connection to AMASPRAY
+
.
The external job is started and ended via the
connected computer.
Emergency termination on AMASPRAY
+
:
Actuate keys
and simultaneously.
Fig.
11
Fig.
12
