Cleaning, maintenance and repairs
Cirrus 03 BAH0101-05 11.19
303
12.6.5 Check the transport locking mechanism of the implement booms
Only Cirrus 4003-2:
The two bars (Fig. 445/1) form the mechanical
transport lock for the implement booms.
After folding the booms, the bar (Fig. 445/2)
engages automatically.
Check if all components can move freely and
operate correctly.
Fig. 444
Only Cirrus 6003-2:
The mechanical transport lock (Fig. 445/1) is
automatically locked when folding the implement
sections.
Check if all components operate correctly.
Fig. 445
