Structure and function

Cirrus 03 BAH0101-05 11.19

5.14.5 Cirrus (-CC)(-2CC) with two metering units and two distributor heads

Cirrus-CC with two metering units and

two distributor heads have

 2 chambers in the hopper

 1 metering unit at the front (Fig. 98/1)

 1 metering unit at the rear (Fig. 98/2)

for FerTeC coulters

 2 double sluices (Fig. 98/3)

 1 distributor head (Fig. 98/1a)

for RoTeC pro Control coulters or

TwinTeC+ double disc coulters

 1 distributor head (Fig. 98/2a)

for FerTeC coulters.

Fig. 98

The calibration is performed consecutively on

both metering units. The order of the numbered

metering units can be freely selected.

Metering unit at the front (Fig. 98/1)

When calibrating the spread rate and during

operation

 the seed flows out of the front hopper

chamber into the left conveyor tube to the

seed distributor head (Fig. 98/1a)

 the seed rate is not halved during

calibration.

Fig. 99

Metering unit at the rear (Fig. 98/2)

When calibrating the spread rate and during

operation

 the metered material flows out of the rear

hopper chamber into the right conveyor tube

to the FerTeC distributor head (Fig. 98/2a)

 the metered quantity is not halved during

calibration.

Fig. 100
