BPI Flash Memory for VCU118 Boards
Prior to Revision 2.0
Configuration Options
[Figure 2-1, callout 35]
The VCU118 board supports two of the seven UltraScale FPGA configuration modes:
• Master BPI using the onboard linear BPI flash memory
•JTAG using:
°
USB JTAG configuration port (Digilent module U115)
°
AMD platform cable 2 mm, keyed flat cable header (J3)
See UltraScale Architecture Configuration User Guide (UG570) [Ref 2] for further details on
configuration modes.
Each configuration interface corresponds to one or more configuration modes and bus
widths as listed in Table 3-35. The mode switches M2, M1, and M0 are on SW16 positions 2,
3, and 4, respectively. The FPGA default mode setting M[2:0] = 010, selecting the master BPI
configuration mode.
TableC‐1: VCU118 Board FPGA Configuration Modes
Configuration
Mode
SW16 DIP Switch
Settings (M[2:0])
Bus Width CCLK Direction
Master BPI 010 x8, x16 Output
JTAG 101 x1 Not applicable
