VCU118 Board User Guide 85
UG1224 (v1.5) March 15, 2023
Chapter3: Board Component Descriptions
User I/O
[Figure 2-1, callouts 23, 24, 25, 26]
The VCU118 board provides these user and general purpose I/O capabilities:
Eight user LEDs (callout 24)
°
GPIO_LED[7-0]: DS31, DS32, DS33, DS10, DS19, DS8, DS6, DS7
Five user pushbuttons and CPU reset switch (callout 25)
°
GPIO_SW [NESWC]: SW10, SW9, SW8, SW6, SW7
°
CPU_RESET: SW5 (near callout 23)
4-position user DIP switch (callout 26)
°
GPIO_DIP_SW[3:0]: SW12
DS40 SYS_5V0 On
DS42 SYSCTLR INIT
DS43 SYSCTLR status
DS44 SYSCTLR done
DS45 SYSCTLR error
DS46 SYS_1V0 On
DS47 DDR4 C2 VTT On
DS48 RLD3 C1 VTT On
DS49 UTIL_1V35 On
EPHY J10 RT. GREEN ENET PHY LINK1000
EPHY J10 LFT. GREEN ENET link activity
Table328: VCU118 Board Status and User LEDs (Cont’d)
