Status and User LEDs
[Figure 2-1, callouts 24]
Table 3-28 defines VCU118 board status and user LEDs.
Table3‐28: VCU118 Board Status and User LEDs
Reference Designator Description
DS1 ENET PHY link
DS2 FPGA INIT
DS3 Combined power good
DS4 SYS_2V2 ON
DS5 VCCINTIO_BRAM On
DS6 GPIO_LED_1
DS7 GPIO_LED_0
DS8 GPIO_LED_2
DS9 GPIO_LED_5
DS10 GPIO_LED_4
DS12 GPIO_LED_5
DS13 GPIO_LED_6
DS14 UTIL_3V3 On
DS15 MGTAVCC On
DS16 VCC1V2 On
DS17 MGTAVTT On
DS18 GPIO_LED_7
DS19 VADJ_1V8 On
DS20 12V power available at power input jack J15
DS21 VCCINT On
DS24 VCC1V8 On
DS25 MGTVCCAUX On
DS26 12V On
DS27 SYS_2V5 On
DS28 SYS_1V8 On
DS31 GPIO_LED_7
DS32 GPIO_LED_6
DS33 GPIO_LED_5
DS34 FPGA done
DS36 DDR4 C1 VTT On
