VCU118 Board User Guide 123
UG1224 (v1.5) March 15, 2023
AppendixC: BPI Flash Memory for VCU118 Boards Prior to Revision 2.0
BPI Flash Memory Constraints
# BPI FLASH
# BPI_FLASH_D[3:0] are wired to FPGA U1 Bank 0
# CONFIGURATION BITS D[3:0} ARE NOT USER ACCESSIBLE
# PACKAGE_PIN AP11 - BPI_FLASH_D0 Bank 0 - D00_MOSI_0
# PACKAGE_PIN AN11 - BPI_FLASH_D1 Bank 0 - D01_DIN_0
# PACKAGE_PIN AM11 - BPI_FLASH_D2 Bank 0 - D02_0
# PACKAGE_PIN AL11 - BPI_FLASH_D3 Bank 0 - D03_0
# PACKAGE_PIN AJ11 - BPI_FLASH_CE_B Bank 0 - RDWR_FCS_B_0
set_property PACKAGE_PIN AM19 [get_ports "BPI_FLASH_D4"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_D4"];
set_property PACKAGE_PIN AM18 [get_ports "BPI_FLASH_D5"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_D5"];
set_property PACKAGE_PIN AN20 [get_ports "BPI_FLASH_D6"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_D6"];
set_property PACKAGE_PIN AP20 [get_ports "BPI_FLASH_D7"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_D7"];
set_property PACKAGE_PIN AN19 [get_ports "BPI_FLASH_D8"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_D8"];
set_property PACKAGE_PIN AN18 [get_ports "BPI_FLASH_D9"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_D9"];
set_property PACKAGE_PIN AR18 [get_ports "BPI_FLASH_D10"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_D10"];
set_property PACKAGE_PIN AR17 [get_ports "BPI_FLASH_D11"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_D11"];
set_property PACKAGE_PIN AT20 [get_ports "BPI_FLASH_D12"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_D12"];
set_property PACKAGE_PIN AT19 [get_ports "BPI_FLASH_D13"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_D13"];
set_property PACKAGE_PIN AT17 [get_ports "BPI_FLASH_D14"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_D14"];
set_property PACKAGE_PIN AU17 [get_ports "BPI_FLASH_D15"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_D15"];
set_property PACKAGE_PIN AR20 [get_ports "BPI_FLASH_A0"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_A0"];
set_property PACKAGE_PIN AR19 [get_ports "BPI_FLASH_A1"];
