AppendixC: BPI Flash Memory for VCU118 Boards Prior to Revision 2.0
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_A1"];
set_property PACKAGE_PIN AV20 [get_ports "BPI_FLASH_A2"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_A2"];
set_property PACKAGE_PIN AW20 [get_ports "BPI_FLASH_A3"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_A3"];
set_property PACKAGE_PIN AU19 [get_ports "BPI_FLASH_A4"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_A4"];
set_property PACKAGE_PIN AU18 [get_ports "BPI_FLASH_A5"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_A5"];
set_property PACKAGE_PIN AV19 [get_ports "BPI_FLASH_A6"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_A6"];
set_property PACKAGE_PIN AV18 [get_ports "BPI_FLASH_A7"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_A7"];
set_property PACKAGE_PIN AW18 [get_ports "BPI_FLASH_A8"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_A8"];
set_property PACKAGE_PIN AY18 [get_ports "BPI_FLASH_A9"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_A9"];
set_property PACKAGE_PIN AY19 [get_ports "BPI_FLASH_A10"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_A10"];
set_property PACKAGE_PIN BA19 [get_ports "BPI_FLASH_A11"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_A11"];
set_property PACKAGE_PIN BA17 [get_ports "BPI_FLASH_A12"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_A12"];
set_property PACKAGE_PIN BB17 [get_ports "BPI_FLASH_A13"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_A13"];
set_property PACKAGE_PIN BB19 [get_ports "BPI_FLASH_A14"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_A14"];
set_property PACKAGE_PIN BC19 [get_ports "BPI_FLASH_A15"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_A15"];
set_property PACKAGE_PIN BB18 [get_ports "BPI_FLASH_A16"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_A16"];
set_property PACKAGE_PIN BC18 [get_ports "BPI_FLASH_A17"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_A17"];
set_property PACKAGE_PIN AY20 [get_ports "BPI_FLASH_A18"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_A18"];
set_property PACKAGE_PIN BA20 [get_ports "BPI_FLASH_A19"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_A19"];
set_property PACKAGE_PIN BD18 [get_ports "BPI_FLASH_A20"];
