VCU118 Board User Guide 125
UG1224 (v1.5) March 15, 2023
AppendixC: BPI Flash Memory for VCU118 Boards Prior to Revision 2.0
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_A20"];
set_property PACKAGE_PIN BD17 [get_ports "BPI_FLASH_A21"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_A21"];
set_property PACKAGE_PIN BC20 [get_ports "BPI_FLASH_A22"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_A22"];
set_property PACKAGE_PIN BD20 [get_ports "BPI_FLASH_A23"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_A23"];
set_property PACKAGE_PIN BE18 [get_ports "BPI_FLASH_A24"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_A24"];
set_property PACKAGE_PIN BE17 [get_ports "BPI_FLASH_A25"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_A25"];
set_property PACKAGE_PIN BE20 [get_ports "BPI_FLASH_A26"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_A26"];
set_property PACKAGE_PIN AW17 [get_ports "BPI_FLASH_ADV"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_ADV"];
set_property PACKAGE_PIN BF16 [get_ports "BPI_FLASH_FWE_B"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_FWE_B"];
set_property PACKAGE_PIN BF17 [get_ports "BPI_FLASH_OE_B"];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_FLASH_OE_B"];
set_property PACKAGE_PIN AL19 [get_ports "BPI_WAIT "];
set_property IOSTANDARD LVCMOS18 [get_ports "BPI_WAIT "];
